Product Information
Description
Model: TWS-TSO32HVGT
The TECO TWS-TSO32HVGT is a 3.2kW inverter reverse-cycle split-system air conditioner designed for year-round heating and cooling. Its variable-capacity inverter system delivers rated cooling and heating capacity of 3.20kW, with output able to adjust to changing room conditions.
The system uses a rotary compressor and R410A refrigerant, with three indoor fan speeds plus Turbo mode. Maximum indoor cooling airflow is 164L/s, while the indoor sound pressure level is rated at 44dB(A) at one metre.
Cooling input is rated at 810W with a 3.0-star rating, while heating input is 830W with a 3.0-star rating. The system operates from a 220–240V single-phase 50Hz supply, with power connected at the outdoor unit.
For installation flexibility, the system supports up to 15m of refrigerant pipe and a maximum 5m height difference between indoor and outdoor units. The indoor unit measures 814mm wide and weighs 9.5kg, while the outdoor unit measures 760mm wide and weighs 29kg.
Product Dimensions
| Indoor Unit Dimensions (W × H × D) | 814 × 306 × 210 mm |
| Indoor Unit Net Weight | 9.5 kg |
| Outdoor Unit Dimensions (W × H × D) | 760 × 551 × 256 mm |
| Outdoor Unit Net Weight | 29.0 kg |
Specifications
| Brand | TECO |
| Model Number | TWS-TSO32HVGT |
| Indoor Model Number | TWS32HVGT |
| Outdoor Model Number | TSO32HVGT |
| Condition | Brand New |
| Product Type | Split System Air Conditioner |
| System Type | Wall-Mounted Split System |
| Operation | Reverse Cycle |
| Technology | Inverter |
| Cooling Capacity | 3.20 kW |
| Cooling Capacity Range | 1.05–3.70 kW |
| Cooling Running Current | 3.8 A |
| Cooling Running Current Range | 1.3–7.0 A |
| Cooling Input | 810 W |
| Cooling AEER | 3.70 |
| Cooling Star Rating | 3.0 Star |
| Heating Capacity | 3.20 kW |
| Heating Capacity Range | 1.05–4.30 kW |
| Heating Running Current | 3.7 A |
| Heating Running Current Range | 1.3–7.0 A |
| Heating Input | 830 W |
| Heating AEER | 3.70 |
| Heating Star Rating | 3.0 Star |
| Power Supply | 220–240 V |
| Phase / Frequency | 1 Phase / 50 Hz |
| Power Supply Attachment | Outdoor Unit |
| Moisture Removal | 1.2 L/s |
| Indoor Fan Speeds | 3 + Turbo |
| Maximum Indoor Cooling Airflow | 164 L/s |
| Compressor Type | Rotary |
| Indoor Sound Pressure Level | 44 dB(A) @ 1 m |
| Outdoor Sound Pressure Level | 55 dB(A) @ 1 m |
| Outdoor Sound Power Level | 65 dB(A) |
| Refrigerant | R410A |
| Liquid Pipe Size | 6.35 mm / 1/4 inch |
| Gas Pipe Size | 9.52 mm / 3/8 inch |
| Maximum Pipe Length | 15 m |
| Maximum Height Difference | 5 m |
| Pipe Connection Method | Flare |
| Indoor Unit Height | 306 mm |
| Indoor Unit Width | 814 mm |
| Indoor Unit Depth | 210 mm |
| Indoor Unit Net Weight | 9.5 kg |
| Outdoor Unit Height | 551 mm |
| Outdoor Unit Width | 760 mm |
| Outdoor Unit Depth | 256 mm |
| Outdoor Unit Net Weight | 29.0 kg |
| Cooling Ambient Operating Range | -7 to 52 °C |
| Heating Ambient Operating Range | -15 to 24 °C |
Delivery Information:
- Our drivers will deliver, unpack, install, and remove your old appliance.
- Excludes cabinet, electrical, venting, plumbing, mounting, or door removals.
- Plumbed fridges will be unpacked and placed only; a plumber may be required.
- Delivery and access must be feasible and safe for a two-man crew.
- $80 fee for cancellations or returns requested on delivery day.
- Redelivery or any approved returns will incur additional charges.
- If you do not allow the delivery company to open the appliances upon delivery, responsibility for any later-discovered damage rests with the customer.
Description
Model: TWS-TSO32HVGT
The TECO TWS-TSO32HVGT is a 3.2kW inverter reverse-cycle split-system air conditioner designed for year-round heating and cooling. Its variable-capacity inverter system delivers rated cooling and heating capacity of 3.20kW, with output able to adjust to changing room conditions.
The system uses a rotary compressor and R410A refrigerant, with three indoor fan speeds plus Turbo mode. Maximum indoor cooling airflow is 164L/s, while the indoor sound pressure level is rated at 44dB(A) at one metre.
Cooling input is rated at 810W with a 3.0-star rating, while heating input is 830W with a 3.0-star rating. The system operates from a 220–240V single-phase 50Hz supply, with power connected at the outdoor unit.
For installation flexibility, the system supports up to 15m of refrigerant pipe and a maximum 5m height difference between indoor and outdoor units. The indoor unit measures 814mm wide and weighs 9.5kg, while the outdoor unit measures 760mm wide and weighs 29kg.
Features
- 3.20kW rated cooling and heating capacity
- Inverter reverse-cycle operation for year-round comfort
- Three fan speeds plus Turbo mode with up to 164L/s airflow
- R410A refrigerant with rotary compressor
- Supports up to 15m pipe length and 5m height difference
Product Dimensions
| Indoor Unit Dimensions (W × H × D) | 814 × 306 × 210 mm |
| Indoor Unit Net Weight | 9.5 kg |
| Outdoor Unit Dimensions (W × H × D) | 760 × 551 × 256 mm |
| Outdoor Unit Net Weight | 29.0 kg |
